Πλαίσιο:

Spark Carbon HMF
Integrated Suspension Technology
Flex Pivot / Adjustable head angle
Syncros Cable Integration System
BB92 / UDH Interface / 12x148mm with 55mm Chainline

Πιρούνι:

FOX 36SL Float Performance Elite Air Grip SL
3-Modes, Kabolt 15x110mm Axle
44mm offset, tapered steerer, Reb. Adj., Lockout
140mm travel

Οπίσθια Ανάρτηση:

FOX NUDE 6T EVOL Trunnion
SCOTT custom w. travel, geo adj.
3 modes: Lockout-Traction Control-Descend
Low Speed Adj., Custom large Air volume, Reb. Adj.
Bearing Hardware, Travel 120-80-Lockout, T165X45mm

Αριθμός ταχυτήτων:

12

Ποτήρια Λαιμού:

Syncros - Acros Angle adjust & Cable Routing HS System
+-0.6° head angle adjustment
ZS56/28.6 – ZS56/40 MTB

Οπίσθιος εκτροχιαστής:

Shimano XT Di2 RD-M8250 SGS, 12 Speed
Wireless Electronic Shift System

Χειριστήρια ταχυτήτων:

Shimano XT Di2 SW-M8250-IR
Ispec EV clamp

Δισκοβραχίονας:

Shimano XT FC-M8200-1
Hollowtech 2
55mm CL, 32T

Μεσαία Τριβή:

Shimano XT BB-7141, shell 41x92mm

Κασέτα γραναζιών:

Shimano XT CS-M8100-12 / 10-51 T

Αλυσίδα:

Shimano XT CN-M8100

Έξτρα:

Shimano Di2 Powerpack

Σετ τροχών:

Syncros Silverton 2.0-30 CL
F: 15x110mm, R: 12x148mm
30mm Tubeless ready rim 28H / Micro Spline
Syncros Axle w/Removable Lever
with 6mm Allen, T30 and T25 Tools

Ελαστικό Οπίσθιο:

Maxxis Forekaster, 29x2.4", 60TPI Foldable
Tubeless Ready, EXO 3C maxx Terra

Ελαστικό Εμπρόσθιο:

Maxxis Forekaster, 29x2.4", 60TPI Foldable
Tubeless Ready, EXO 3C maxx Terra

Φρένα:

Shimano XT M8220 4 Piston Disc

Δίσκοι Φρένων:

Shimano RT-CL700 , F&R 180mm

Τιμόνι:

Syncros Fraser iC SL DC Carbon
0° rise / back sweep 8° / mini Rise / 760mm
Syncros Performance XC lock-on grips

Ντίζα σέλας:

S size 110mm, M size 140mm, L size 160mm, XL size 180mm
Syncros Duncan Dropper 1.5S, Travel Adjust, 31.6mm

Σέλα:

Syncros Tofino 1.5 Regular
Titanium rails

Βάρος (kg):

12.6 (Tubless setup)
